Tractor · 2006Unverified
Minot 20
Minot 20 — Compact Utility tractor · 20 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
20 hp
Weight
2425 to 2660 pounds
Hover a source tag to verify
Overview
DistributorMinotReference
ManufacturerJinmaReference
Compact Utility tractorReference
Built in ChinaReference
Original price was $6,700 in 2006Reference
Two-wheel driveReference
SteeringpowerReference
Two-post foldable ROPS with canopy.Reference
Variants
2420similar Farm Pro modelReference
Engine
1.2L 2-cyl dieselReference
Engine (gross)14.9 kWReference
TY290Reference
dieselReference
2-cylinderReference
liquid-cooled inlineReference
Displacement1.2 LReference
Bore/Stroke90 x 100 mmReference
Power (gross)14.9 kWReference
Pre-heatingglow plugsReference
Rated RPM2300Reference
StarterelectricReference
Starter volts12Reference
Oil capacity3.5 LReference
Coolant capacity10.0 LReference
Transmission
12-speedReference
Gears12 forward and 4 reverseReference
Oil capacity11.0 LReference
Capacities
Fuel20.8 LReference
PTO & Hydraulics
Hydraulic system9.1 LReference
Typeopen centerReference
Capacity9.1 LReference
Total flow11.4 lpmReference
Rear lift0 kgReference
Rear lift (at 24"/610mm)367 kgReference
Rear PTOlive (two-stage clutch)Reference
Rear PTO Type540 (1.375)Reference
Dimensions
Wheelbase152 cmReference
Weight2425 to 2660 poundsReference
Front tire6.00-12Reference
Rear tire8.3-24Reference
Ag front6.00-12Reference
Ag rear8.3-24Reference
Length290 cmReference
Width142 cmReference
Height218 cmReference
Shipping weight1099 kgReference
Operating weight1206 kgReference
Ground clearance25 cmReference
Front tread95 cmReference
Rear tread94 to 109 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
