Tractor · 2006Unverified
Minot 25
Minot 25 — Compact Utility tractor · 25 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
25 hp
Weight
1240 kg
Hover a source tag to verify
Overview
DistributorMinotReference
ManufacturerJinmaReference
Compact Utility tractorReference
Built in ChinaReference
Original price was $12,779 in 2006Reference
Four-wheel driveReference
SteeringpowerReference
Two-post foldable ROPS with canopy.Reference
Engine
1.4L 3-cyl dieselReference
Engine (gross)18.6 kWReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.4 LReference
Bore/Stroke85 x 85 mmReference
Power (gross)18.6 kWReference
Pre-heatingglow plugsReference
Rated RPM2350Reference
StarterelectricReference
Starter volts12Reference
Oil capacity6.0 LReference
Coolant capacity7.9 LReference
Transmission
12-speedReference
Gears12 forward and 4 reverseReference
Oil capacity14.0 LReference
Capacities
Fuel22.0 LReference
Front axle4.5 LReference
PTO & Hydraulics
Hydraulic system9.1 LReference
Capacity9.1 LReference
Total flow11.4 lpmReference
Rear lift0 kgReference
Rear lift (at 24"/610mm)396 kgReference
Rear PTOlive (two-stage clutch)Reference
Rear PTO Type540/1000Reference
Dimensions
Wheelbase165 cmReference
Weight1240 kgReference
Front tire6.00-16Reference
Rear tire9.5-24Reference
Ag front6.00-16Reference
Ag rear9.5-24Reference
Length299 cmReference
Width144 cmReference
Height218 cmReference
Shipping weight1240 kgReference
Ground clearance25 cmReference
Front tread107 cmReference
Rear tread106 to 124 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
