Tractor · 2006Unverified
Minot 30 II
Minot 30 II — Compact Utility tractor · 30 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
30 hp
Weight
3494 to 3858 pounds
Hover a source tag to verify
Overview
DistributorMinotReference
ManufacturerJinmaReference
Compact Utility tractorReference
Built in ChinaReference
Four-wheel driveReference
SteeringpowerReference
Two-post foldable ROPS with canopy.Reference
Engine
1.8L 4-cyl dieselReference
Engine (gross)22.4 kWReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement1.8 LReference
Bore/Stroke80 x 90 mmReference
Power (gross)22.4 kWReference
Pre-heatingglow plugsReference
Rated RPM2200Reference
StarterelectricReference
Starter volts12Reference
Oil capacity6.0 LReference
Coolant capacity7.2 LReference
Transmission
8-speedReference
Gears8 forward and 2 reverseReference
Oil capacity18.5 LReference
Capacities
Fuel29.9 LReference
Front axle6.6 LReference
PTO & Hydraulics
Hydraulic system8.7 LReference
Capacity8.7 LReference
Total flow18.2 lpmReference
Rear TypeIReference
Rear lift (at 24"/610mm)649 kgReference
Rear PTOlive (two-stage clutch)Reference
Rear PTO Type540/720Reference
Dimensions
Wheelbase167 cmReference
Weight3494 to 3858 poundsReference
Front tire7.5-16Reference
Rear tire11.2-24Reference
Ag front7.5-16Reference
Ag rear11.2-24Reference
Length306 cmReference
Width144 cmReference
Height198 cmReference
Shipping weight1584 kgReference
Operating weight1749 kgReference
Ground clearance29 cmReference
Front tread119 to 145 cmReference
Rear tread115 to 145 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
