Tractor · 2008Unverified
Mitsubishi GA28
Mitsubishi GA28 — GA Series · 29 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
29 hp
Weight
3219 to 3593.5 pounds
Hover a source tag to verify
Overview
ManufacturerMitsubishiReference
Compact Utility tractorReference
Four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Two-post ROPS. Cab optional.Reference
Engine
Iseki 1.5L 3-cyl dieselReference
Fuel tank37.9 LReference
Engine21.5 kWReference
Iseki E3CDReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.5 LReference
Bore/Stroke87 x 84 mmReference
Power21.5 kWReference
Rated RPM2500Reference
StarterelectricReference
Starter volts12Reference
Transmission
24-speedReference
Gears24 forward and reverseReference
Clutchwet discReference
PTO & Hydraulics
Rear TypeIReference
Controlposition controlReference
Rear lift1788 kgReference
Rear PTO Type565/746/949/1210 (1.375)Reference
Dimensions
Wheelbase166 cmReference
Weight3219 to 3593.5 poundsReference
Front tire7-16Reference
Rear tire11.2-24Reference
Standard tires (ag)Front: 7-16. Rear: 11.2-24Reference
Length326 cmReference
Width151 cmReference
Height (ROPS)246 cmReference
Height (cab)210 cmReference
ROPS Weight1460 kgReference
Cab Weight1630 kgReference
Ground clearance33 cmReference
Front tread106 cmReference
Rear tread104 to 113 cmReference
Electrical
GroundnegativeReference
Battery CCA630Reference
Battery volts12Reference
Battery AH68Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
