Tractor · 2008Unverified

Mitsubishi GA28

Name: Mitsubishi GA28
Brand: Mitsubishi

Mitsubishi GA28 — GA Series · 29 hp. Reference specifications; pending source verification.

The Mitsubishi GA28 is a compact tractor with a rated output of 29 hp. It was in production from 2008 to 2016. The model features a 3-cylinder diesel liquid-cooled engine, coupled to a 24-speed gearbox that drives the four-wheel drive. The listed weight of the tractor falls within the range of 3219 to 3593.5 pounds.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

29 hp

Weight

3219 to 3593.5 pounds

Catalogue coverage

Variants represented

Richest spec table

44 rows

Recorded power

29 hp

Recorded weight

1460 kg

Transmissions

24-speed

Production years

2008-2016

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerMitsubishiReference

Compact Utility tractorReference

Four-wheel driveReference

Power steeringReference

Wet disc brakesReference

Two-post ROPS. Cab optional.Reference

Engine

Iseki 1.5L 3-cyl dieselReference

Fuel tank37.9 LReference

Engine21.5 kWReference

Iseki E3CDReference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement1.5 LReference

Bore/Stroke87 x 84 mmReference

Power21.5 kWReference

Rated RPM2500Reference

StarterelectricReference

Starter volts12Reference

Transmission

24-speedReference

Gears24 forward and reverseReference

Clutchwet discReference

PTO & Hydraulics

Rear TypeIReference

Controlposition controlReference

Rear lift1788 kgReference

Rear PTO Type565/746/949/1210 (1.375)Reference

Dimensions

Wheelbase166 cmReference

Weight3219 to 3593.5 poundsReference

Front tire7-16Reference

Rear tire11.2-24Reference

Standard tires (ag)Front: 7-16. Rear: 11.2-24Reference

Length326 cmReference

Width151 cmReference

Height (ROPS)246 cmReference

Height (cab)210 cmReference

ROPS Weight1460 kgReference

Cab Weight1630 kgReference

Ground clearance33 cmReference

Front tread106 cmReference

Rear tread104 to 113 cmReference

Electrical

GroundnegativeReference

Battery CCA630Reference

Battery volts12Reference

Battery AH68Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
