Tractor · 2016Unverified
Mitsubishi GA330
Mitsubishi GA330 — GA Series · 33 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
33 hp
Weight
3571 to 3968 pounds
Hover a source tag to verify
Overview
ManufacturerMitsubishiReference
Compact Utility tractorReference
Four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Two-post ROPS. Cab optional.Reference
Variants
GA330wheeled tractorReference
GAK330half-trackReference
Engine
Shibaura 1.7L 3-cyl dieselReference
Fuel tank37.9 LReference
Engine24.6 kWReference
Shibaura N3LDI-TReference
turbocharged dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.7 LReference
Bore/Stroke84 x 100 mmReference
Power24.6 kWReference
Fuel systemdirect injectionReference
Rated RPM2600Reference
StarterelectricReference
Starter volts12Reference
Transmission
24-speedReference
32-speedReference
Gears24 forward and reverseReference
Clutchwet discReference
Gears32 forward and reverseReference
PTO & Hydraulics
Rear TypeIReference
Controlposition controlReference
Rear lift1788 kgReference
Rear PTO Type4-speed (1.375)Reference
Dimensions
Wheelbase169 cmReference
Weight3571 to 3968 poundsReference
Front tire8-16Reference
Rear tire12.4-26Reference
Standard tires (ag)Front: 8-16. Rear: 12.4-26Reference
Length331 cmReference
Width151 cmReference
Height (ROPS)247 cmReference
Height (cab)217 cmReference
ROPS Weight1619 kgReference
Cab Weight1799 kgReference
Ground clearance35 cmReference
Front tread111 cmReference
Rear tread109 to 139 cmReference
Electrical
GroundnegativeReference
Battery CCA630Reference
Battery volts12Reference
Battery AH68Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
