Tractor · 2008Unverified
Mitsubishi GA41
Mitsubishi GA41 — GA Series · 41 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
41 hp
Weight
3990 to 4442 pounds
Hover a source tag to verify
Overview
ManufacturerMitsubishiReference
Compact Utility tractorReference
Four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Two-post ROPS. Cab optional.Reference
Variants
GA41wheeled tractorReference
GAK41half-trackReference
Engine
Iseki 2.2L 4-cyl dieselReference
Fuel tank54.9 LReference
Engine30.6 kWReference
Iseki E4CGReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement2.2 LReference
Bore/Stroke87 x 92 mmReference
Power30.6 kWReference
Rated RPM2500Reference
StarterelectricReference
Starter volts12Reference
Transmission
32-speedReference
Gears32 forward and reverseReference
Clutchwet discReference
PTO & Hydraulics
Rear TypeIReference
Controlposition controlReference
Rear lift1914 kgReference
Rear PTO Type562763/957/1207 (1.375)Reference
Dimensions
Wheelbase193 cmReference
Weight3990 to 4442 poundsReference
Front tire8-18Reference
Rear tire13.6-26Reference
Standard tires (ag)Front: 8-18. Rear: 13.6-26Reference
Length364 cmReference
Width169 cmReference
Height (ROPS)248 cmReference
Height (cab)227 cmReference
ROPS Weight1809 kgReference
Cab Weight2014 kgReference
Ground clearance36 cmReference
Front tread121 cmReference
Rear tread121 to 151 cmReference
Electrical
GroundnegativeReference
Battery CCA750Reference
Battery volts12Reference
Battery AH80Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
