Tractor · 2016Unverified
Mitsubishi GA450
Mitsubishi GA450 — GA Series · 46 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
46 hp
Weight
4277 to 4729 pounds
Hover a source tag to verify
Overview
ManufacturerMitsubishiReference
Compact Utility tractorReference
Four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Two-post ROPS. Cab optional.Reference
Variants
GA450wheeled tractorReference
GAK450half-trackReference
Engine
Shibaura 2.2L 4-cyl dieselReference
Fuel tank54.9 LReference
Engine34.0 kWReference
Shibaura N4LDI-TReference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement2.2 LReference
Bore/Stroke84 x 100 mmReference
Power34.0 kWReference
Fuel systemdirect injectionReference
Rated RPM2500Reference
StarterelectricReference
Starter volts12Reference
Transmission
32-speedReference
Gears32 forward and reverseReference
Clutchwet discReference
PTO & Hydraulics
Rear TypeIReference
Controlposition controlReference
Rear lift1914 kgReference
Rear PTO Type4-speed (1.375)Reference
Dimensions
Wheelbase193 cmReference
Weight4277 to 4729 poundsReference
Front tire8.3-20Reference
Rear tire13.6-28Reference
Standard tires (ag)Front: 8.3-20. Rear: 13.6-28Reference
Length354 cmReference
Width169 cmReference
Height (ROPS)250 cmReference
Height (cab)232 cmReference
ROPS Weight1940 kgReference
Cab Weight2145 kgReference
Ground clearance38 cmReference
Front tread121 cmReference
Rear tread121 to 151 cmReference
Electrical
GroundnegativeReference
Battery CCA750Reference
Battery volts12Reference
Battery AH85Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
