Tractor · 2008Unverified
Mitsubishi GA50
Mitsubishi GA50 — GA Series · 50 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
50 hp
Weight
4112 to 4564 pounds
Hover a source tag to verify
Overview
ManufacturerMitsubishiReference
Compact Utility tractorReference
Four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Two-post ROPS. Cab optional.Reference
Variants
GA50wheeled tractorReference
GAK50half-trackReference
Engine
Iseki 3.0L 4-cyl dieselReference
Fuel tank54.9 LReference
Engine37.3 kWReference
Iseki E4DEReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.0 LReference
Bore/Stroke97 x 100 mmReference
Power37.3 kWReference
Rated RPM2500Reference
StarterelectricReference
Starter volts12Reference
Transmission
32-speedReference
Gears32 forward and reverseReference
Clutchwet discReference
PTO & Hydraulics
Rear TypeIReference
Controlposition controlReference
Rear lift1914 kgReference
Rear PTO Type562763/957/1207 (1.375)Reference
Dimensions
Wheelbase197 cmReference
Weight4112 to 4564 poundsReference
Front tire8.3-20Reference
Rear tire13.6-28Reference
Standard tires (ag)Front: 8.3-20. Rear: 13.6-28Reference
Length364 cmReference
Width169 cmReference
Height (ROPS)251 cmReference
Height (cab)230 cmReference
ROPS Weight1865 kgReference
Cab Weight2070 kgReference
Ground clearance38 cmReference
Front tread124 cmReference
Rear tread121 to 151 cmReference
Electrical
GroundnegativeReference
Battery CCA750Reference
Battery volts12Reference
Battery AH80Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
