Tractor · 2016Unverified

Mitsubishi GA500

Name: Mitsubishi GA500
Brand: Mitsubishi

Mitsubishi GA500 — GA Series · 50 hp. Reference specifications; pending source verification.

The Mitsubishi GA500 is a tractor model rated at approximately 50 hp, placing it at the lighter end of its class. It was produced in 2016. Equipped with a 4-cylinder turbocharged diesel liquid-cooled engine and four-wheel drive with a 32-speed gearbox, the GA500 has an operating weight of 4277 to 4729 pounds. It is suited for operations of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

50 hp

Weight

4277 to 4729 pounds

Catalogue coverage

Variants represented

Richest spec table

47 rows

Recorded power

50 hp

Recorded weight

1940 kg

Transmissions

32-speed

Production years

2016-2016

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerMitsubishiReference

Compact Utility tractorReference

Four-wheel driveReference

Power steeringReference

Wet disc brakesReference

Two-post ROPS. Cab optional.Reference

Variants

GA500wheeled tractorReference

GAK500half-trackReference

Engine

Shibaura 2.2L 4-cyl dieselReference

Fuel tank54.9 LReference

Engine36.9 kWReference

Shibaura N4LDI-TReference

turbocharged dieselReference

4-cylinderReference

liquid-cooledReference

Displacement2.2 LReference

Bore/Stroke84 x 100 mmReference

Power36.9 kWReference

Fuel systemdirect injectionReference

Rated RPM2600Reference

StarterelectricReference

Starter volts12Reference

Transmission

32-speedReference

Gears32 forward and reverseReference

Clutchwet discReference

PTO & Hydraulics

Rear TypeIReference

Controlposition controlReference

Rear lift1914 kgReference

Rear PTO Type4-speed (1.375)Reference

Dimensions

Wheelbase197 cmReference

Weight4277 to 4729 poundsReference

Front tire8.3-20Reference

Rear tire13.6-28Reference

Standard tires (ag)Front: 8.3-20. Rear: 13.6-28Reference

Length354 cmReference

Width169 cmReference

Height (ROPS)250 cmReference

Height (cab)232 cmReference

ROPS Weight1940 kgReference

Cab Weight2145 kgReference

Ground clearance38 cmReference

Front tread124 cmReference

Rear tread121 to 151 cmReference

Electrical

GroundnegativeReference

Battery CCA750Reference

Battery volts12Reference

Battery AH85Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
