Tractor · 2008Unverified
Mitsubishi GAK32
Mitsubishi GAK32 — GA Series · 33 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
33 hp
Weight
4277 to 4652 pounds
Hover a source tag to verify
Overview
ManufacturerMitsubishiReference
Half-track Crawler tractorReference
Drivehalf-trackReference
Power steeringReference
Wet disc brakesReference
Two-post ROPS. Cab optional.Reference
Variants
GA32wheeled tractorReference
GAK32half-trackReference
Engine
Iseki 1.6L 3-cyl dieselReference
Fuel tank46.2 LReference
Engine24.3 kWReference
Iseki E3CGReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.6 LReference
Bore/Stroke87 x 92 mmReference
Power24.3 kWReference
Rated RPM2600Reference
StarterelectricReference
Starter volts12Reference
Transmission
24-speedReference
Gears24 forward and reverseReference
Clutchwet discReference
PTO & Hydraulics
Rear TypeIReference
Controlposition controlReference
Rear lift1788 kgReference
Rear PTO Type588/776/987/1258 (1.375)Reference
Dimensions
Wheelbase172 cmReference
Weight4277 to 4652 poundsReference
Front tire8-18Reference
Rear tiretracksReference
Ag front8-18Reference
Ag rear400mm tracksReference
Length326 cmReference
Width166 cmReference
Height (ROPS)250 cmReference
Height (cab)214 cmReference
ROPS Weight1940 kgReference
Cab Weight2110 kgReference
Ground clearance37 cmReference
Front tread125 cmReference
Rear tread114 cmReference
Electrical
GroundnegativeReference
Battery CCA630Reference
Battery volts12Reference
Battery AH68Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
