Tractor · 2008Unverified

Mitsubishi GAK36

Name: Mitsubishi GAK36
Brand: Mitsubishi

Mitsubishi GAK36 — GA Series · 36 hp. Reference specifications; pending source verification.

The Mitsubishi GAK36 is a compact tractor with a rated output of 36 hp. Produced from 2008 to 2016, this model features a 3-cylinder diesel liquid-cooled engine and a tracked undercarriage, coupled with a 24-speed gearbox. The listed weight of the GAK36 ranges from 4277 to 4652 pounds. It is designed to handle jobs of approximately 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

36 hp

Weight

4277 to 4652 pounds

Catalogue coverage

Variants represented

Richest spec table

47 rows

Recorded power

36 hp

Recorded weight

1940 kg

Transmissions

24-speed

Production years

2008-2016

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerMitsubishiReference

Half-track Crawler tractorReference

Drivehalf-trackReference

Power steeringReference

Wet disc brakesReference

Two-post ROPS. Cab optional.Reference

Variants

GA36wheeled tractorReference

GAK36half-trackReference

Engine

Iseki 1.6L 3-cyl dieselReference

Fuel tank46.2 LReference

Engine26.9 kWReference

Iseki E3CGReference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement1.6 LReference

Bore/Stroke87 x 92 mmReference

Power26.9 kWReference

Rated RPM2600Reference

StarterelectricReference

Starter volts12Reference

Transmission

24-speedReference

Gears24 forward and reverseReference

Clutchwet discReference

PTO & Hydraulics

Rear TypeIReference

Controlposition controlReference

Rear lift1788 kgReference

Rear PTO Type588/776/987/1258 (1.375)Reference

Dimensions

Wheelbase172 cmReference

Weight4277 to 4652 poundsReference

Front tire8-18Reference

Rear tiretracksReference

Ag front8-18Reference

Ag rear400mm tracksReference

Length326 cmReference

Width166 cmReference

Height (ROPS)250 cmReference

Height (cab)214 cmReference

ROPS Weight1940 kgReference

Cab Weight2110 kgReference

Ground clearance37 cmReference

Front tread125 cmReference

Rear tread114 cmReference

Electrical

GroundnegativeReference

Battery CCA630Reference

Battery volts12Reference

Battery AH68Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
