Tractor · 2016Unverified
Mitsubishi GAK360
Mitsubishi GAK360 — GA Series · 37 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
37 hp
Weight
4464 to 4861 pounds
Hover a source tag to verify
Overview
ManufacturerMitsubishiReference
Half-track Crawler tractorReference
Drivehalf-trackReference
Power steeringReference
Wet disc brakesReference
Two-post ROPS. Cab optional.Reference
Variants
GA360wheeled tractorReference
GAK360half-trackReference
Engine
Shibaura 1.7L 3-cyl dieselReference
Fuel tank45.0 LReference
Engine27.4 kWReference
Shibaura N3LDI-TReference
turbocharged dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.7 LReference
Bore/Stroke84 x 100 mmReference
Power27.4 kWReference
Fuel systemdirect injectionReference
Rated RPM2600Reference
StarterelectricReference
Starter volts12Reference
Transmission
24-speedReference
Gears24 forward and reverseReference
Clutchwet discReference
PTO & Hydraulics
Rear TypeIReference
Controlposition controlReference
Rear lift1788 kgReference
Rear PTO Type4-speed (1.375)Reference
Dimensions
Wheelbase172 cmReference
Weight4464 to 4861 poundsReference
Front tire8-18Reference
Rear tiretracksReference
Ag front8-18Reference
Ag rear400mm tracksReference
Length331 cmReference
Width165 cmReference
Height (ROPS)247 cmReference
Height (cab)217 cmReference
ROPS Weight2024 kgReference
Cab Weight2204 kgReference
Ground clearance37 cmReference
Front tread125 cmReference
Rear tread114 cmReference
Electrical
GroundnegativeReference
Battery CCA630Reference
Battery volts12Reference
Battery AH68Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
