Tractor · 2008Unverified
Mitsubishi GAK41
Mitsubishi GAK41 — GA Series · 41 hp. Reference specifications; pending source verification.
The Mitsubishi GAK41 is a compact tractor, rated at 41 hp, which positions it among the smaller options in its class. It was manufactured from 2008 to 2016. The GAK41 features a 4-cylinder diesel liquid-cooled engine, coupled with a 32-speed gearbox and a tracked undercarriage. Its listed operating weight is 2454 kg and it is designed for use on plots of up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
41 hp
Weight
2454 kg
Catalogue coverage
Variants represented
2
Richest spec table
44 rows
Recorded power
41 hp
Recorded weight
2454 kg
Transmissions
32-speed
Production years
2008-2016
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerMitsubishiReference
Half-track Crawler tractorReference
Drivehalf-trackReference
Power steeringReference
Wet disc brakesReference
Cab standard.Reference
Variants
GA41wheeled tractorReference
GAK41half-trackReference
Engine
Iseki 2.2L 4-cyl dieselReference
Fuel tank50.0 LReference
Engine30.6 kWReference
Iseki E4CGReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement2.2 LReference
Bore/Stroke87 x 92 mmReference
Power30.6 kWReference
Rated RPM2500Reference
StarterelectricReference
Starter volts12Reference
Transmission
32-speedReference
Gears32 forward and reverseReference
Clutchwet discReference
PTO & Hydraulics
Rear TypeIReference
Controlposition controlReference
Rear lift1914 kgReference
Rear PTO Type562/763/957/1207 (1.375)Reference
Dimensions
Wheelbase193 cmReference
Weight2454 kgReference
Front tire8.3-20Reference
Rear tiretracksReference
Ag front8.3-20Reference
Ag rear400mm tracksReference
Length364 cmReference
Width168 cmReference
Height (cab)233 cmReference
Ground clearance40 cmReference
Front tread124 cmReference
Rear tread128 cmReference
Electrical
GroundnegativeReference
Battery CCA750Reference
Battery volts12Reference
Battery AH80Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
