Tractor · 2008Unverified
Mitsubishi GAK50
Mitsubishi GAK50 — GA Series · 50 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
50 hp
Weight
5027 to 5490 pounds
Hover a source tag to verify
Overview
ManufacturerMitsubishiReference
Half-track Crawler tractorReference
Drivehalf-trackReference
Power steeringReference
Wet disc brakesReference
Two-post ROPS. Cab optional.Reference
Variants
GA50wheeled tractorReference
GAK50half-trackReference
Engine
Iseki 3.0L 4-cyl dieselReference
Fuel tank50.0 LReference
Engine37.3 kWReference
Iseki E4DEReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.0 LReference
Bore/Stroke97 x 100 mmReference
Power37.3 kWReference
Rated RPM2500Reference
StarterelectricReference
Starter volts12Reference
Transmission
32-speedReference
Gears32 forward and reverseReference
Clutchwet discReference
PTO & Hydraulics
Rear TypeIReference
Controlposition controlReference
Rear lift1914 kgReference
Rear PTO Type562/763/957/1207 (1.375)Reference
Dimensions
Wheelbase197 cmReference
Weight5027 to 5490 poundsReference
Front tire8.3-20Reference
Rear tiretracksReference
Ag front8.3-20Reference
Ag rear400mm tracksReference
Length364 cmReference
Width168 cmReference
Height (ROPS)254 cmReference
Height (cab)233 cmReference
ROPS Weight2280 kgReference
Cab Weight2490 kgReference
Ground clearance40 cmReference
Front tread124 cmReference
Rear tread128 cmReference
Electrical
GroundnegativeReference
Battery CCA750Reference
Battery volts12Reference
Battery AH80Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
