Tractor · 2006Unverified
Mitsubishi GCR65
Mitsubishi GCR65 — GCR Series · 64 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
64 hp
Weight
3620 kg
Hover a source tag to verify
Overview
ManufacturerMitsubishiReference
Agricultural Crawler tractorReference
DrivecrawlerReference
Cab standard with air-conditioning.Reference
Engine
Mitsubishi 3.3L 4-cyl dieselReference
Fuel tank129.8 LReference
Engine47.8 kWReference
Mitsubishi S4S-DTReference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.3 LReference
Bore/Stroke94 x 120 mmReference
Power47.8 kWReference
Rated RPM2500Reference
Starter volts12Reference
Transmission
hydrostaticReference
TypehydrostaticReference
Gearsinfinite forward and reverse (2-range)Reference
PTO & Hydraulics
Rear TypeJISII/JISIReference
Rear lift3289 kgReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Engine RPM582@2500Reference
Engine RPM797@2500Reference
Engine RPM1055@2500Reference
Dimensions
Weight3620 kgReference
17.7-inch tracksReference
Length388 cmReference
Width180 cmReference
Height257 cmReference
Ground clearance39 cmReference
Gauge135 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Mitsubishi GCR65 Tracks
Width44 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
