Tractor · 2013Unverified
Mitsubishi GKS235
Mitsubishi GKS235 — GS Series · 23 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
23 hp
Weight
1305 kg
Hover a source tag to verify
Overview
ManufacturerMitsubishiReference
Half-track Crawler tractorReference
Drivehalf-trackReference
Power steeringReference
Two-post ROPS.Reference
Variants
GS231wheeledReference
GSK235half-trackReference
Engine
Isuzu 1.5L 3-cyl dieselReference
Fuel tank25.0 LReference
Engine17.3 kWReference
Isuzu E3CDReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.5 LReference
Bore/Stroke86 x 86 mmReference
Power17.3 kWReference
Rated RPM2500Reference
StarterelectricReference
Starter volts12Reference
Transmission
12-speedReference
Gears12 forward and reverseReference
Four gears in three ranges with shuttle.Reference
PTO & Hydraulics
Rear TypeJIS0Reference
Rear PTO Type540 (1.375)Reference
Engine RPM523@2500Reference
Engine RPM819@2500Reference
Engine RPM1266@2500Reference
Engine RPM-505@2500Reference
Engine RPM-792@2500Reference
Engine RPM-1224@2500Reference
Dimensions
Wheelbase150 cmReference
Weight1305 kgReference
Front tire7-14Reference
Rear tiretracksReference
Ag front7-14Reference
Ag rear400mm tracksReference
Length283 cmReference
Width143 cmReference
Height (ROPS)199 cmReference
Ground clearance41 cmReference
Front tread96 cmReference
Rear tread103 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Speeds
Reverse speeds are 15% slower than forward.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
