Tractor · 2016Unverified
Mitsubishi GM500
Mitsubishi GM500 — GM Series · 50 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
50 hp
Weight
4332 to 4652 pounds
Hover a source tag to verify
Overview
ManufacturerMitsubishiReference
Compact Utility tractorReference
Four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Two-post ROPS. Cab optional.Reference
Engine
Shibaura 2.2L 4-cyl dieselReference
Fuel tank54.9 LReference
Engine36.9 kWReference
Shibaura N4LDI-TReference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement2.2 LReference
Bore/Stroke84 x 100 mmReference
Power36.9 kWReference
Fuel systemdirect injectionReference
Rated RPM2600Reference
StarterelectricReference
Starter volts12Reference
Transmission
16-speed syncromeshReference
TypesyncromeshReference
Gears16 forward and reverseReference
Clutchdry discReference
Four gears (1-4) in four ranges (creeper, low, medium, and high) with shuttle shift.Reference
PTO & Hydraulics
Rear TypeIReference
Controlposition controlReference
Rear lift1901 kgReference
Rear PTO Type573/819/1328 (1.375)Reference
Dimensions
Wheelbase198 cmReference
Weight4332 to 4652 poundsReference
Front tire8-18Reference
Rear tire13.6-28Reference
Standard tires (ag)Front: 8-18. Rear: 13.6-28Reference
Length353 cmReference
Width155 cmReference
Height (ROPS)251 cmReference
Height (cab)231 cmReference
ROPS Weight1964 kgReference
Cab Weight2110 kgReference
Ground clearance37 cmReference
Front tread124 cmReference
Rear tread121 to 171 cmReference
Electrical
GroundnegativeReference
Battery CCA565Reference
Battery volts12Reference
Battery AH80Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
