Tractor · 2016Unverified

Mitsubishi GM550

Name: Mitsubishi GM550
Brand: Mitsubishi

Mitsubishi GM550 — GM Series · 54 hp. Reference specifications; pending source verification.

The Mitsubishi GM550 is a tractor with a rating of approximately 54 hp, positioning it within the lighter categories of its class. It was manufactured in 2016. It is equipped with a 4-cylinder turbocharged diesel liquid-cooled engine, combined with four-wheel drive and a 16-speed gearbox. The tractor has a listed operating weight of 4343 to 4663 pounds and is suited for operations covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

54 hp

Weight

4343 to 4663 pounds

Catalogue coverage

Variants represented

Richest spec table

47 rows

Recorded power

54 hp

Recorded weight

1969 kg

Transmissions

16-speed syncromesh

Production years

2016-2016

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerMitsubishiReference

Compact Utility tractorReference

Four-wheel driveReference

Power steeringReference

Wet disc brakesReference

Two-post ROPS. Cab optional.Reference

Engine

Shibaura 2.2L 4-cyl dieselReference

Fuel tank54.9 LReference

Engine40.6 kWReference

Shibaura N4LDI-TAReference

turbocharged dieselReference

4-cylinderReference

liquid-cooledReference

Displacement2.2 LReference

Bore/Stroke84 x 100 mmReference

Power40.6 kWReference

Fuel systemdirect injectionReference

Rated RPM2600Reference

StarterelectricReference

Starter volts12Reference

Transmission

16-speed syncromeshReference

TypesyncromeshReference

Gears16 forward and reverseReference

Clutchdry discReference

Four gears (1-4) in four ranges (creeper, low, medium, and high) with shuttle shift.Reference

PTO & Hydraulics

Rear TypeIReference

Controlposition controlReference

Rear lift1901 kgReference

Rear PTO Type573/819/1328 (1.375)Reference

Dimensions

Wheelbase198 cmReference

Weight4343 to 4663 poundsReference

Front tire8-18Reference

Rear tire13.6-28Reference

Standard tires (ag)Front: 8-18. Rear: 13.6-28Reference

Length353 cmReference

Width155 cmReference

Height (ROPS)251 cmReference

Height (cab)231 cmReference

ROPS Weight1969 kgReference

Cab Weight2115 kgReference

Ground clearance37 cmReference

Front tread124 cmReference

Rear tread121 to 171 cmReference

Electrical

GroundnegativeReference

Battery CCA565Reference

Battery volts12Reference

Battery AH80Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
