The Mitsubishi GS160 is a lightweight tractor model with a rated power output of 16 hp, positioning it at the lower end of its class. It was manufactured from 2006 to 2012. The GS160 features a 3-cylinder diesel liquid-cooled engine, paired with four-wheel drive and a 12-speed gearbox, and has an operating weight of 820 kg. It is suitable for operations on areas of up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
16 hp
Weight
820 kg
Catalogue coverage
Variants represented
2
Richest spec table
39 rows
Recorded power
16 hp
Recorded weight
820 kg
Transmissions
12-speed
Production years
2006-2012
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerMitsubishiReference
Compact Utility tractorReference
Four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Two-post ROPS.Reference
Engine
Mitsubishi 1.1L 3-cyl dieselReference
Fuel tank25.7 LReference
Engine11.8 kWReference
Mitsubishi S3LReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.1 LReference
Bore/Stroke78 x 79 mmReference
Power11.8 kWReference
Rated RPM2500Reference
Starter volts12Reference
Transmission
12-speedReference
Gears12 forward and reverseReference
PTO & Hydraulics
Rear TypeJIS0Reference
Rear PTO Type540 (1.375)Reference
Engine RPM566@2500Reference
Engine RPM815@2500Reference
Engine RPM1310@2500Reference
Engine RPM-952@2500Reference
Dimensions
Wheelbase137 cmReference
Weight820 kgReference
Front tire6-12Reference
Rear tire8.3-20Reference
Standard tires (ag)Front: 6-12. Rear: 8.3-20Reference
Length264 cmReference
Width106 cmReference
Height (ROPS)186 cmReference
Ground clearance31 cmReference
Front tread85 cmReference
Rear tread81/96 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
