Tractor · 2018Unverified
Mitsubishi GS252
Mitsubishi GS252 — GS Series · 25 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
25 hp
Weight
2127 to 2624 pounds
Hover a source tag to verify
Overview
ManufacturerMitsubishiReference
Compact Utility tractorReference
Four-wheel driveReference
Power steeringReference
Two-post ROPS. Cab optional with air-conditioning.Reference
Engine
Mitsubishi 1.3L 3-cyl dieselReference
Fuel tank23.1 LReference
Engine18.4 kWReference
Mitsubishi S3L2Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.3 LReference
Bore/Stroke78 x 92 mmReference
Power18.4 kWReference
Rated RPM2500Reference
StarterelectricReference
Starter volts12Reference
Transmission
12-speed gearReference
30-speed partial power shiftReference
TypegearReference
Gears12 forward and reverseReference
Four gears in three ranges with shuttle.Reference
Typepartial power shiftReference
Gears30 forward and 15 reverseReference
Ten gears forward, five reverse, in three ranges.Reference
PTO & Hydraulics
Rear TypeJIS0Reference
Rear PTO Type540 (1.375)Reference
Engine RPM566@2500Reference
Engine RPM816@2500Reference
Engine RPM1310@2500Reference
Engine RPM-952@2500Reference
Dimensions
ROPS Wheelbase145 cmReference
Cab Wheelbase150 cmReference
Weight2127 to 2624 poundsReference
Front tire7-14Reference
Rear tire9.5-24Reference
Standard tires (ag)Front: 7-14. Rear: 9.5-24Reference
ROPS Length271 cmReference
Cab Length278 cmReference
ROPS Width116 cmReference
Cab Width127 cmReference
Height (ROPS)195 cmReference
Height (cab)197 cmReference
ROPS Weight964 kgReference
Cab Weight1190 kgReference
Ground clearance37 cmReference
ROPS Front tread92 cmReference
Cab Front tread101 cmReference
Rear tread88/103 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
