Tractor · 2003Unverified
Mitsubishi GSK18
Mitsubishi GSK18 — GS Series · 18 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
18 hp
Weight
929 kg
Hover a source tag to verify
Overview
ManufacturerMitsubishiReference
Half-track Crawler tractorReference
Drivehalf-trackReference
Power steeringReference
Wet disc brakesReference
Two-post ROPS.Reference
Engine
Isuzu 1.0L 3-cyl dieselReference
Fuel tank25.0 LReference
Engine13.2 kWReference
Isuzu E3100Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.0 LReference
Bore/Stroke74 x 78 mmReference
Power13.2 kWReference
Rated RPM2500Reference
StarterelectricReference
Starter volts12Reference
Transmission
6-speedReference
Gears6 forward and 2 reverseReference
Clutchdry discReference
PTO & Hydraulics
Rear TypeJIS0Reference
Rear PTO Type540 (1.375)Reference
Engine RPM500@2500Reference
Engine RPM774@2500Reference
Engine RPM1266@2500Reference
Engine RPM-861@2500Reference
Dimensions
Wheelbase134 cmReference
Weight929 kgReference
Front tire6.00-12Reference
Rear tiretracksReference
Ag front6.00-12Reference
Ag rear330mm tracksReference
Length262 cmReference
Width125 cmReference
Height (ROPS)184 cmReference
Ground clearance36 cmReference
Front tread87 cmReference
Rear tread89 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
