The Mitsubishi GSK190 is a tractor with a power output of approximately 19 hp, positioning it towards the lower end of its class. It was manufactured from 2006 to 2012 and is equipped with a 3-cylinder diesel liquid-cooled engine, paired with a tracked undercarriage and a 12-speed gearbox. The tractor has a listed operating weight of 1035 kg and is suitable for use on areas of up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
19 hp
Weight
1035 kg
Catalogue coverage
Variants represented
2
Richest spec table
44 rows
Recorded power
19 hp
Recorded weight
1035 kg
Transmissions
12-speed
Production years
2006-2012
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerMitsubishiReference
Half-track Crawler tractorReference
Drivehalf-trackReference
Power steeringReference
Wet disc brakesReference
Two-post ROPS.Reference
Engine
Iseki 1.1L 3-cyl dieselReference
Fuel tank25.0 LReference
Engine14.0 kWReference
Iseki E3112Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.1 LReference
Bore/Stroke78 x 78 mmReference
Power14.0 kWReference
Rated RPM2500Reference
StarterelectricReference
Starter volts12Reference
Transmission
12-speedReference
Gears12 forward and reverseReference
Clutchdry discReference
PTO & Hydraulics
Rear TypeJIS0Reference
Rear PTO Type540 (1.375)Reference
Engine RPM523@2500Reference
Engine RPM783@2500Reference
Engine RPM1184@2500Reference
Engine RPM-505@2500Reference
Engine RPM-757@2500Reference
Engine RPM-1145@2500Reference
Dimensions
Wheelbase135 cmReference
Weight1035 kgReference
Front tire6.00-12Reference
Rear tiretracksReference
Ag front6.00-12Reference
Ag rear330mm tracksReference
Length270 cmReference
Width123 cmReference
Height (ROPS)199 cmReference
Ground clearance39 cmReference
Front tread88 cmReference
Rear tread88 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
