Tractor · 2018Unverified
Mitsubishi GSK226
Mitsubishi GSK226 — GS Series · 22 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
22 hp
Weight
1035 kg
Hover a source tag to verify
Overview
ManufacturerMitsubishiReference
Half-track Crawler tractorReference
Drivehalf-trackReference
Power steeringReference
Two-post ROPS.Reference
Engine
Iseki 1.1L 3-cyl dieselReference
Fuel tank28.0 LReference
Engine16.1 kWReference
Iseki E3112Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.1 LReference
Bore/Stroke78 x 78 mmReference
Power16.1 kWReference
Rated RPM2500Reference
StarterelectricReference
Starter volts12Reference
Transmission
12-speedReference
Gears12 forward and reverseReference
PTO & Hydraulics
Rear TypeJIS0Reference
Rear PTO Type540 (1.375)Reference
Engine RPM544@2500Reference
Engine RPM815@2500Reference
Engine RPM1231@2500Reference
Engine RPM-526@2500Reference
Engine RPM-788@2500Reference
Engine RPM-1190@2500Reference
Dimensions
Wheelbase135 cmReference
Weight1035 kgReference
Front tire6-14Reference
Rear tiretracksReference
Ag front6-14Reference
Ag rear330mm tracksReference
Length260 cmReference
Width125 cmReference
Height (ROPS)197 cmReference
Ground clearance34 cmReference
Front tread88 cmReference
Rear tread89 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
