Tractor · 2018Unverified
Mitsubishi GSK236
Mitsubishi GSK236 — GS Series · 23 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
23 hp
Weight
1384 kg
Hover a source tag to verify
Overview
ManufacturerMitsubishiReference
Half-track Crawler tractorReference
Drivehalf-trackReference
Power steeringReference
Two-post ROPS.Reference
Engine
Isuzu 1.5L 3-cyl dieselReference
Fuel tank28.0 LReference
Engine17.3 kWReference
Isuzu E3CDReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.5 LReference
Bore/Stroke86 x 86 mmReference
Power17.3 kWReference
Rated RPM2500Reference
StarterelectricReference
Starter volts12Reference
Transmission
12-speedReference
Gears12 forward and reverseReference
PTO & Hydraulics
Rear TypeJIS0Reference
Rear PTO Type540 (1.375)Reference
Engine RPM523@2500Reference
Engine RPM819@2500Reference
Engine RPM1266@2500Reference
Engine RPM-505@2500Reference
Engine RPM-792@2500Reference
Engine RPM-1224@2500Reference
Dimensions
Wheelbase150 cmReference
Weight1384 kgReference
Front tire7-16Reference
Rear tiretracksReference
Ag front7-16Reference
Ag rear370mm tracksReference
Length290 cmReference
Width139 cmReference
Height (ROPS)199 cmReference
Ground clearance37 cmReference
Front tread103 cmReference
Rear tread103 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
