Tractor · 2013Unverified
Mitsubishi GSK255
Mitsubishi GSK255 — GS Series · 26 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
26 hp
Weight
2877 to 3296 pounds
Hover a source tag to verify
Overview
ManufacturerMitsubishiReference
Half-track Crawler tractorReference
Drivehalf-trackReference
Power steeringReference
Two-post ROPS. Cab optional.Reference
Variants
GS251wheeled ROPSReference
GS251Xwheeled cabReference
GSK255half-trackReference
Engine
Isuzu 1.5L 3-cyl dieselReference
Fuel tank25.0 LReference
Engine19.5 kWReference
Isuzu E3CDReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.5 LReference
Bore/Stroke86 x 86 mmReference
Power19.5 kWReference
Rated RPM2500Reference
StarterelectricReference
Starter volts12Reference
Transmission
12-speedReference
Gears12 forward and reverseReference
Four gears in three ranges with shuttle.Reference
PTO & Hydraulics
Rear TypeJIS0Reference
Rear PTO Type540 (1.375)Reference
Engine RPM523@2500Reference
Engine RPM819@2500Reference
Engine RPM1266@2500Reference
Engine RPM-505@2500Reference
Engine RPM-792@2500Reference
Engine RPM-1224@2500Reference
Dimensions
ROPS Wheelbase150 cmReference
Cab Wheelbase154 cmReference
Weight2877 to 3296 poundsReference
Front tire7-14Reference
Rear tiretracksReference
Ag front7-14Reference
Ag rear400mm tracksReference
ROPS Length283 cmReference
Cab Length289 cmReference
Width143 cmReference
Height (ROPS)199 cmReference
Height (cab)199 cmReference
ROPS Weight1305 kgReference
Cab Weight1495 kgReference
Ground clearance41 cmReference
Front tread96 cmReference
Rear tread103 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Speeds
Reverse speeds are 15% slower than forward.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
