Tractor · 2018Unverified

Mitsubishi GSK256

Name: Mitsubishi GSK256
Brand: Mitsubishi

Mitsubishi GSK256 — GS Series · 25 hp. Reference specifications; pending source verification.

The Mitsubishi GSK256 is a compact tractor with a rated power output of 25 hp, manufactured in 2018. It is equipped with a 3-cylinder diesel liquid-cooled engine, coupled to a 12-speed gearbox and a tracked undercarriage. The tractor's weight is listed as 3053 to 3406 pounds. Its operating capacity is reportedly up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

25 hp

Weight

3053 to 3406 pounds

Catalogue coverage

Variants represented

Richest spec table

45 rows

Recorded power

25 hp

Recorded weight

1384 kg

Transmissions

12-speed

Production years

2018-2018

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerMitsubishiReference

Half-track Crawler tractorReference

Drivehalf-trackReference

Power steeringReference

Two-post ROPS. Cab optional with air-conditioning.Reference

Engine

Isuzu 1.5L 3-cyl dieselReference

Fuel tank28.0 LReference

Engine18.4 kWReference

Isuzu E3CDReference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement1.5 LReference

Bore/Stroke86 x 86 mmReference

Power18.4 kWReference

Rated RPM2500Reference

StarterelectricReference

Starter volts12Reference

Transmission

12-speedReference

Gears12 forward and reverseReference

PTO & Hydraulics

Rear TypeJIS0Reference

Rear PTO Type540 (1.375)Reference

Engine RPM523@2500Reference

Engine RPM819@2500Reference

Engine RPM1266@2500Reference

Engine RPM-505@2500Reference

Engine RPM-792@2500Reference

Engine RPM-1224@2500Reference

Dimensions

Wheelbase150 cmReference

Weight3053 to 3406 poundsReference

Front tire7-16Reference

Rear tiretracksReference

Ag front7-16Reference

Ag rear370mm tracksReference

Length290 cmReference

Width139 cmReference

Height (ROPS)199 cmReference

Height (cab)199 cmReference

ROPS Weight1384 kgReference

Cab Weight1544 kgReference

Ground clearance37 cmReference

Front tread103 cmReference

Rear tread103 cmReference

Electrical

GroundnegativeReference

Battery volts12Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
