Tractor · 2005Unverified
Mitsubishi GX46
Mitsubishi GX46 — GX Series · 46 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
46 hp
Weight
1834 kg
Hover a source tag to verify
Overview
ManufacturerMitsubishiReference
Compact Utility tractorReference
Four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Cab standard with available air-condioning.Reference
Engine
Mitsubishi 2.3L 4-cyl dieselReference
Fuel tank54.9 LReference
Engine34.3 kWReference
Mitsubishi K4NReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement2.3 LReference
Bore/Stroke90 x 90 mmReference
Power34.3 kWReference
Rated RPM2600Reference
StarterelectricReference
Starter volts12Reference
Transmission
16-speedReference
Gears16 forward and reverseReference
Clutchdry discReference
PTO & Hydraulics
Rear TypeIReference
Controlposition controlReference
Rear lift1898 kgReference
Rear PTO Type573/819/1328 (1.375)Reference
Dimensions
Wheelbase189 cmReference
Weight1834 kgReference
Front tire9.5-16Reference
Rear tire13.6-28Reference
Standard tires (ag)Front: 9.5-16. Rear: 13.6-28Reference
Length340 cmReference
Width155 cmReference
Height240 cmReference
Ground clearance35 cmReference
Front tread124 cmReference
Rear tread121/132/141/151/161/171 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
