Tractor · 2011Unverified
Mitsubishi GXK401
Mitsubishi GXK401 — GX Series · 40 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
40 hp
Weight
2275 kg
Hover a source tag to verify
Overview
ManufacturerMitsubishiReference
Half-track Crawler tractorReference
Drivehalf-trackReference
Power steeringReference
Wet disc brakesReference
Cab standard with available air-condioning.Reference
Variants
GX401wheeled tractorReference
GXK401half-trackReference
Engine
Mitsubishi 2.2L 4-cyl dieselReference
Fuel tank54.9 LReference
Engine29.8 kWReference
Mitsubishi S4L3-12AReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement2.2 LReference
Power29.8 kWReference
Rated RPM2600Reference
StarterelectricReference
Starter volts12Reference
Transmission
24-speedReference
Gears24 forward and reverseReference
PTO & Hydraulics
Rear TypeIReference
Rear lift1901 kgReference
Rear PTO Type573/819/1328 (1.375)Reference
Dimensions
Wheelbase193 cmReference
Weight2275 kgReference
Front tire8.3-20Reference
Rear tiretracksReference
Ag front8.3-20Reference
Ag reartracksReference
Length340 cmReference
Width167 cmReference
Height230 cmReference
Ground clearance37 cmReference
Front tread124 cmReference
Rear tread128 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
