Tractor · 1984Unverified
Mitsubishi MT160
Mitsubishi MT160 — Compact Utility tractor · 14 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
14 hp
Weight
1246 to 1356 pounds
Hover a source tag to verify
Overview
ManufacturerMitsubishiReference
Compact Utility tractorReference
Two- or four-wheel driveReference
Differential lockmechanical rearReference
Manual steeringReference
Drum brakesReference
Open operator station.Reference
Variants
MT1602WDReference
MT160D4WDReference
Engine
Mitsubishi 0.8L 3-cyl dieselReference
Engine12.3 kWReference
Mitsubishi K3AReference
dieselReference
3-cylinderReference
liquid-cooled inlineReference
Displacement0.8 LReference
Bore/Stroke65 x 78 mmReference
Power12.3 kWReference
Air cleanerdryReference
Compression23:1Reference
Rated RPM2700Reference
Torque45.2 NmReference
Torque RPM1900Reference
Firing order1-3-2Reference
Starter volts12Reference
Oil capacity3.0 LReference
Coolant capacity5.0 LReference
Transmission
6-speed sliding gearReference
Typesliding gearReference
Gears6 forward and 2 reverseReference
Clutchdry discReference
Oil capacity12.0 LReference
PTO & Hydraulics
PTO (claimed)10.1 kWReference
Hydraulic system12.1 LReference
Typeopen centerReference
Capacity12.1 LReference
Pressure132.4 barReference
Pump flow12.9 lpmReference
Rear TypeIReference
Controlposition controlReference
Rear PTO Type540/1000 (1.375)Reference
Engine RPM540@2340Reference
Engine RPM1000@1793Reference
Capacities
Fuel18.2 LReference
Dimensions
Wheelbase142 cmReference
Weight1246 to 1356 poundsReference
Front tire4.00-9Reference
2WD Rear tire8-16Reference
2WD Standard tires (ag)Front: 4.00-9. Rear: 8-16Reference
4WD Standard tires (ag)Front: 5-12. Rear: 8-16Reference
Length219 cmReference
Width97 cmReference
2WD Height (steering wheel)115 cmReference
4WD Height (steering wheel)116 cmReference
2WD Weight565 kgReference
4WD Weight615 kgReference
2WD Ground clearance25 cmReference
4WD Ground clearance21 cmReference
2WD Front tread71 cmReference
4WD Front tread78 cmReference
Rear tread73/88 cmReference
Electrical
GroundnegativeReference
Charging amps35Reference
Battery volts12Reference
Battery AH45Reference
Speeds
With 8-16 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
