Tractor · 1981Unverified
Mitsubishi MT1801
Mitsubishi MT1801 — Compact Utility tractor · 15 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
15 hp
Weight
817 kg
Hover a source tag to verify
Overview
ManufacturerMitsubishiReference
Compact Utility tractorReference
Four-wheel driveReference
Differential lockmechanical rearReference
Open operator station.Reference
Engine
Mitsubishi 1.1L 4-cyl dieselReference
Engine13.4 kWReference
Mitsubishi K4BReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement1.1 LReference
Bore/Stroke68 x 78 mmReference
Power13.4 kWReference
Rated RPM2500Reference
Starter volts12Reference
Transmission
15-speed gearReference
TypegearReference
Gears15 forward and 5 reverseReference
PTO & Hydraulics
PTO (claimed)11.2 kWReference
Dimensions
Wheelbase148 cmReference
Weight817 kgReference
Front tire6.00-12Reference
Rear tire9.5-22Reference
Ag front6.00-12Reference
Ag rear9.5-22Reference
Length256 cmReference
Width117 cmReference
Height134 cmReference
Front tread77 cmReference
Rear tread61 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
