Tractor · 1999Unverified

Mitsubishi MT231

Name: Mitsubishi MT231
Brand: Mitsubishi

Mitsubishi MT231 — GO Series · 23 hp. Reference specifications; pending source verification.

The Mitsubishi MT231 is a compact tractor model with a rated output of 23 hp. It was manufactured from 1999 to 2003 and is equipped with a 4-cylinder diesel liquid-cooled engine, which drives the four-wheel drive system via a 16-speed gearbox. The listed operating weight of the MT231 ranges from 2778 to 3109 pounds. It is designed for use on small to medium-sized farms, handling tasks of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

23 hp

Weight

2778 to 3109 pounds

Catalogue coverage

Variants represented

Richest spec table

40 rows

Recorded power

23 hp

Recorded weight

1260 kg

Transmissions

16-speed

Production years

1999-2003

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerMitsubishiReference

Compact Utility tractorReference

Four-wheel driveReference

Power steeringReference

Wet disc brakesReference

Two-post ROPS. Cab optional.Reference

Engine

Mitsubishi 1.5L 4-cyl dieselReference

Fuel tank28.0 LReference

Engine16.9 kWReference

Mitsubishi S4LReference

dieselReference

4-cylinderReference

liquid-cooledReference

Displacement1.5 LReference

Bore/Stroke78 x 78 mmReference

Power16.9 kWReference

Rated RPM2500Reference

StarterelectricReference

Starter volts12Reference

Transmission

16-speedReference

Gears16 forward and reverseReference

Four gears in four ranges with left-hand shuttle shift.Reference

PTO & Hydraulics

Rear TypeJISIReference

Rear lift1799 kgReference

Rear PTO540 (1.375)Reference

Dimensions

Wheelbase157 cmReference

Weight2778 to 3109 poundsReference

Front tire6-14Reference

Rear tire9.5-24Reference

Standard tires (ag)Front: 6-14. Rear: 9.5-24Reference

Length313 cmReference

Width129 cmReference

Height (ROPS)191 cmReference

ROPS Weight1260 kgReference

Cab Weight1410 kgReference

Ground clearance29 cmReference

Front tread106 cmReference

Rear tread101/116 cmReference

Electrical

GroundnegativeReference

Battery volts12Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
