The Mitsubishi MT338 is a tractor with a rated power output of 33 hp, situated at the lower power end of its class. Manufactured from 2000 to 2004, it features a 4-cylinder diesel liquid-cooled engine, coupled with four-wheel drive and a 16-speed gearbox. The MT338 has an operating weight of 1640 kg and is suitable for operations covering up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
33 hp
Weight
1640 kg
Catalogue coverage
Variants represented
2
Richest spec table
39 rows
Recorded power
33 hp
Recorded weight
1640 kg
Transmissions
16-speed
Production years
2000-2004
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerMitsubishiReference
Compact Utility tractorReference
Four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Cab standard with available air-condioning.Reference
Engine
Mitsubishi 1.8L 4-cyl dieselReference
Fuel tank37.9 LReference
Engine24.6 kWReference
Mitsubishi S4L2Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement1.8 LReference
Bore/Stroke78 x 92 mmReference
Power24.6 kWReference
Rated RPM2500Reference
StarterelectricReference
Starter volts12Reference
Transmission
16-speedReference
Gears16 forward and reverseReference
Clutchdry discReference
PTO & Hydraulics
Rear TypeIReference
Controlposition controlReference
Rear lift1898 kgReference
Rear PTO Type570/787/1277 (1.375)Reference
Dimensions
Wheelbase183 cmReference
Weight1640 kgReference
Front tire8-18Reference
Rear tire12.4-28Reference
Standard tires (ag)Front: 8-18. Rear: 12.4-28Reference
Length340 cmReference
Width147 cmReference
Height235 cmReference
Ground clearance36 cmReference
Front tread121 cmReference
Rear tread115/125/134/144/154/164 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
