The Mitsubishi R1500 is a compact tractor with a rated output of 15 hp. It was manufactured from 1970 to 1975. The tractor features a 1-cylinder diesel liquid-cooled engine, coupled with a 5-speed gearbox and two-wheel drive. Its listed weight is 600 kg and it is designed for use on approximately 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
15 hp
Weight
600 kg
Catalogue coverage
Variants represented
2
Richest spec table
35 rows
Recorded power
15 hp
Recorded weight
600 kg
Transmissions
5-speed gear
Production years
1970-1975
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerMitsubishiReference
Compact Utility tractorReference
Two-wheel driveReference
Open operator station.Reference
Engine
Mitsubishi 0.8L 1-cyl dieselReference
Engine11.0 kWReference
Mitsubishi SDT75Reference
dieselReference
1-cylinderReference
liquid-cooledReference
Displacement0.8 LReference
Bore/Stroke96 x 105 mmReference
Power11.0 kWReference
Rated RPM2400Reference
StarterelectricReference
Starter volts12Reference
Transmission
5-speed gearReference
TypegearReference
Gears5 forward and 1 reverseReference
PTO & Hydraulics
Rear TypeIReference
Rear PTO Type540/816Reference
Dimensions
Wheelbase124 cmReference
Weight600 kgReference
Front tire4.00-12Reference
Rear tire8-20Reference
Ag front4.00-12Reference
Ag rear8-20Reference
Length202 cmReference
Width113 cmReference
Height123 cmReference
Ground clearance38 cmReference
Front tread80 cmReference
Rear tread77/92 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
