Tractor · 2004Unverified
Montana 2740
Montana 2740 — Compact Utility tractor · 27 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
27 hp
Weight
1179 kg
Hover a source tag to verify
Overview
ManufacturerMontanaReference
Compact Utility tractorReference
Four-wheel driveReference
Differential lockmechanical rearReference
Power steeringReference
Wet disc brakesReference
Two-post fixed ROPS.Reference
Engine
Daedong 1.4L 3-cyl dieselReference
Fuel tank28.0 LReference
Engine20.1 kWReference
Daedong 3A139LGReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.4 LReference
Bore/Stroke80 x 92 mmReference
Power20.1 kWReference
Fuel systemindirect injectionReference
Air cleanerdual dry elementReference
Pre-heatingglow plugsReference
Rated RPM2600Reference
Starter volts12Reference
Transmission
8-speed sync shuttleReference
Typesync shuttleReference
Gears8 forward and reverseReference
PTO & Hydraulics
Typeopen centerReference
Valves1Reference
Pump flow21.8 lpmReference
Rear TypeIReference
Controlposition controlReference
Rear lift (at ends)723 kgReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Dimensions
Weight1179 kgReference
Front tire7-14Reference
Rear tire11.2-24Reference
Ag front7-14Reference
Ag rear11.2-24Reference
Lawn/turf front24x8.5-14Reference
Lawn/turf rear41x14-20Reference
Industrial front25x8.5-14Reference
Industrial rear43x16-20Reference
Length293 cmReference
Height (ROPS)236 cmReference
Ground clearance29 cmReference
Montana 2740 attachments
front-end loaderReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps50Reference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
