The Montana 4320 is a tractor with a rated power output of approximately 43 horsepower, positioning it in the lighter category of its class. Production of the 4320 spanned the period from 2005 to 2009. The tractor features a 4-cylinder diesel liquid-cooled engine and four-wheel drive, paired with a 16-speed gearbox. It has an operating weight of 2296 kg and is suitable for use on areas of up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
43 hp
Weight
2296 kg
Catalogue coverage
Variants represented
2
Richest spec table
48 rows
Recorded power
43 hp
Recorded weight
2296 kg
Transmissions
16-speed sync shuttle
Production years
2005-2009
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
DistributorMontanaReference
ManufacturerLGReference
Compact Utility tractorReference
Two-wheel driveReference
Differential lockmechanical rearReference
Power steeringReference
Wet disc brakesReference
Two-post fixed ROPS. Big Sky cab optional.Reference
Variants
43202WD ROPSReference
4320C2WD CabReference
43404WD ROPSReference
4340C4WD CabReference
Engine
Mitsubishi 2.3L 4-cyl dieselReference
Fuel tank51.1 LReference
Engine32.1 kWReference
Mitsubishi S4QSReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement2.3 LReference
Bore/Stroke88 x 95 mmReference
Power32.1 kWReference
Fuel systemindirect injectionReference
Air cleanerdual dry elementReference
Pre-heatingglow plugsReference
Rated RPM2600Reference
Starter volts12Reference
Transmission
16-speed sync shuttleReference
Typesync shuttleReference
Gears16 forward and reverseReference
PTO & Hydraulics
Valves2Reference
Pump flow31.9 lpmReference
Rear TypeIReference
Controlposition and draft controlReference
Rear lift (at ends)1450 kgReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Dimensions
Weight2296 kgReference
Front tire8.3-20Reference
Rear tire12.4-28Reference
Ag front8.3-20Reference
Ag rear12.4-28Reference
Length319 cmReference
Height (cab)237 cmReference
Ground clearance34 cmReference
Electrical
GroundnegativeReference
Charging amps45Reference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
