Tractor · 2005Unverified
Montana 4340
Montana 4340 — Compact Utility tractor · 43 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
43 hp
Weight
4188.7 to 5063.9 pounds
Hover a source tag to verify
Overview
DistributorMontanaReference
ManufacturerLGReference
Compact Utility tractorReference
Four-wheel driveReference
Differential lockmechanical rearReference
Power steeringReference
Wet disc brakesReference
Two-post ROP.Big Sky cab optional.Reference
Variants
43202WD ROPSReference
4320C2WD CabReference
43404WD ROPSReference
4340C4WD CabReference
Engine
Mitsubishi 2.3L 4-cyl dieselReference
Cab Fuel tank51.1 LReference
ROPS Fuel tank60.2 LReference
Engine32.1 kWReference
Mitsubishi S4QSReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement2.3 LReference
Bore/Stroke88 x 95 mmReference
Power32.1 kWReference
Fuel systemindirect injectionReference
Air cleanerdual dry elementReference
Pre-heatingglow plugsReference
Rated RPM2600Reference
Starter volts12Reference
Transmission
16-speed sync shuttleReference
Typesync shuttleReference
Gears16 forward and reverseReference
PTO & Hydraulics
Valves2Reference
Pump flow31.9 lpmReference
Rear TypeIReference
Controlposition and draft controlReference
Rear lift (at ends)1450 kgReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Dimensions
Wheelbase189 cmReference
Weight4188.7 to 5063.9 poundsReference
Front tire8.3-20Reference
Rear tire12.4-28Reference
Ag front8.3-20Reference
Ag rear12.4-28Reference
Lawn/turf front9.5-16Reference
Lawn/turf rear14.9-24Reference
Industrial front12-16.5Reference
Industrial rear17.5-24Reference
Length319 cmReference
Height237 cmReference
Cab Weight2296 kgReference
ROPS Weight1899 kgReference
Ground clearance34 cmReference
Montana 4340 attachments
front-end loaderReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps45Reference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
