Tractor · 2005Unverified
Montana 4920
Montana 4920 — Compact Utility tractor · 49 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
49 hp
Weight
4321 to 5202.8 pounds
Hover a source tag to verify
Overview
DistributorMontanaReference
ManufacturerLGReference
Compact Utility tractorReference
Two-wheel driveReference
Differential lockmechanical rearReference
Power steeringReference
Wet disc brakesReference
Two-post ROPS. Big Sky cab optional.Reference
Variants
49202WD ROPSReference
4920C2WD CabReference
49404WD ROPSReference
4940C4WD CabReference
Engine
Mitsubishi 2.5L 4-cyl dieselReference
Cab Fuel tank51.1 LReference
ROPS Fuel tank60.2 LReference
Engine36.5 kWReference
Mitsubishi S4QLReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement2.5 LReference
Bore/Stroke88 x 103 mmReference
Power36.5 kWReference
Fuel systemindirect injectionReference
Air cleanerdual dry elementReference
Rated RPM2500Reference
Starter volts12Reference
Transmission
16-speed sync shuttleReference
Typesync shuttleReference
Gears16 forward and reverseReference
PTO & Hydraulics
Valves2Reference
Pump flow31.9 lpmReference
Rear TypeIReference
Controlposition and draft controlReference
Rear lift (at ends)1450 kgReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Dimensions
Weight4321 to 5202.8 poundsReference
Front tire9.5-20Reference
Rear tire13.6-28Reference
Ag front9.5-20Reference
Ag rear13.6-28Reference
Length319 cmReference
Width133 cmReference
Width164 cmReference
Height240 cmReference
Cab Weight2359 kgReference
ROPS Weight1960 kgReference
Ground clearance36 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps45Reference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
