Tractor · 2007Unverified
Montana R4344
Montana R4344 — R Series · 41 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
41 hp
Weight
1624 kg
Hover a source tag to verify
Overview
DistributorMontanaReference
ManufacturerLSReference
Compact Utility tractorReference
Four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Two-post folding ROPS.Reference
Variants
CT41similar McCormick Intl modelReference
Engine
Mitsubishi 2.3L 4-cyl dieselReference
Fuel tank37.9 LReference
Engine (gross)30.6 kWReference
Mitsubishi S4QSReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement2.3 LReference
Bore/Stroke88 x 95 mmReference
Power (gross)30.6 kWReference
Fuel systemindirect injectionReference
Air cleanerdry dual elementReference
Pre-heatingglow plugsReference
Rated RPM2600Reference
Starter volts12Reference
Transmission
16-speed sync shuttleReference
hydrostaticReference
Typesync shuttleReference
Gears16 forward and reverseReference
TypehydrostaticReference
Gearsinfinite forward and reverse (3-range)Reference
PTO & Hydraulics
Gear PTO (claimed)26.8 kWReference
Hydro PTO (claimed)25.4 kWReference
Pressure176.5 barReference
Valves2Reference
Pump flow31.0 lpmReference
Steering flow15.6 lpmReference
Steering press.142.2 barReference
Rear TypeIReference
Rear lift (at ends)1249 kgReference
Rear PTOtransmissionReference
Rear PTO Type540 (1.375)Reference
Mid PTOoptionalReference
Dimensions
Wheelbase175 cmReference
Weight1624 kgReference
Front tire8-16Reference
Rear tire12.4-24Reference
Weight396 kgReference
Ag front8-16Reference
Ag rear12.4-24Reference
Industrial front28x8.5-15Reference
Industrial rear43x16-20Reference
Length317 cmReference
Height241 cmReference
Ground clearance35 cmReference
Montana R4344 attachments
front-end loaderReference
backhoeReference
R4344 Serial Numbers
Location:Serial number plate on the right side of the tractor frame, above the front axle.Reference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps50Reference
Battery volts12Reference
Attachment overview
Front-end loaderReference
BackhoeReference
Montana MBH76 Backhoe
Backhoe typeMontana MBH76 BackhoeReference
Transport height175 cmReference
Digging depth243 cmReference
2-Foot flat digging depth228 cmReference
Reach from pivot289 cmReference
Loading height177 cmReference
Bucket Rotation180°Reference
Swing Arc180°Reference
Bucket force1288 kgReference
Dipperstick force909 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
