The Montana T2334 is a compact tractor, boasting a rated output of 23 hp, and is characterised by its compact design. It features a 3-cylinder diesel liquid-cooled engine and a hydrostatic transmission, driving through four-wheel drive. The tractor's weight is listed as 750 kg, and it is suitable for use on areas of up to 200 acres. Production of this model took place from 2006 to 2009.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
23 hp
Weight
750 kg
Catalogue coverage
Variants represented
2
Richest spec table
50 rows
Recorded power
23 hp
Recorded weight
750 kg
Transmissions
hydrostatic
Production years
2006-2009
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerMontanaReference
Compact Utility tractorReference
Four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Two-post folding ROPS.Reference
Engine
Mitsubishi 1.1L 3-cyl dieselReference
Fuel tank25.0 LReference
Engine17.2 kWReference
Mitsubishi S3LReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.1 LReference
Bore/Stroke78 x 79 mmReference
Power17.2 kWReference
Air cleanersingle dry elementReference
Rated RPM2700Reference
Starter volts12Reference
Transmission
hydrostaticReference
TypehydrostaticReference
Gearsinfinite forward and reverse (2-range)Reference
PTO & Hydraulics
Typeopen centerReference
Valves1Reference
Pump flow18.9 lpmReference
Total flow28.8 lpmReference
Rear TypeIReference
Rear lift (at 24"/610mm)550 kgReference
Rear PTO Type540Reference
Mid PTOstandardReference
Mid PTO Type2000Reference
Dimensions
Wheelbase148 cmReference
Weight750 kgReference
Front tire6-12Reference
Rear tire9.5-20Reference
Ag front6-12Reference
Ag rear9.5-20Reference
Lawn/turf front23x8.50-12Reference
Lawn/turf rear12-16.5Reference
Industrial front23X8.50-12Reference
Industrial rear12-16.5Reference
Length233 cmReference
Width124 cmReference
Height199 cmReference
Ground clearance29 cmReference
Montana T2334 attachments
front-end loaderReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps50Reference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
