Lawn Tractor · 1972Unverified
MTD 380
MTD 380 — Lawn tractor · 5 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
5 hp
Weight
136 kg
Hover a source tag to verify
Overview
ManufacturerMTDReference
Lawn tractorReference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Variants
380recoil startReference
385electric startReference
Engine
5HP Briggs & Stratton 206cc 1-cyl gasolineReference
Briggs & Stratton 130000Reference
gasolineReference
1-cylinderReference
air-cooled vertical-shaftReference
Displacement12.57 ciReference
Bore/Stroke65 x 62 mmReference
Power (gross)3.7 kWReference
Startermanual recoilReference
StarterelectricReference
Starter volts12Reference
Transmission
1-speed gearReference
TransmissionMTDReference
Typebelt-driven gearReference
Gears1 forward and reverseReference
Transmission part number 717-0222 used through 1978. Number 717-0223 used from 1979 to 1981.Reference
PTO & Hydraulics
Mid PTOindependentReference
Clutchmanual idler pulleyReference
Dimensions
Weight136 kgReference
Front tire10.25x3.25Reference
Rear tire13x5.0Reference
Lawn/turf front10.25x3.25Reference
Lawn/turf rear13x5.0Reference
Shipping weight136 kgReference
MTD 380 attachments
26" mid-mount mower deckReference
380 Serial Numbers
1972132-380 (model code)Reference
1973133-380 (model code)Reference
1974134-380A (model code)Reference
1975135-380A (model code)Reference
1976136-380A (model code)Reference
1977137-380A (model code)Reference
1978138-380A (model code)Reference
1979139-380A (model code)Reference
1980130-380A (model code)Reference
1981131-380A (model code)Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Battery volts12Reference
26" Mower deck
Typemid-mount MTDReference
Type1-blade with manual liftReference
Cutting width66 cmReference
Cut positions5Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
