Tractor · 2005Unverified

Müller STA160

Name: Müller STA160
Brand: Müller

Müller STA160 — Four-wheel Drive (4WD) tractor · 152 hp. Reference specifications; pending source verification.

The Müller STA160 is a tractor characterised by its 152 hp rated power, placing it at the more powerful end of its class, and was manufactured in 2005. It features a 6-cylinder turbocharged diesel liquid-cooled engine, coupled with four-wheel drive and a 12-speed gearbox. The Müller STA160 has a listed operating weight of 7098 kg, and it is suited to tasks on land areas ranging from 200 to 800 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

152 hp

Weight

7098 kg

Catalogue coverage

Variants represented

Richest spec table

49 rows

Recorded power

152 hp

Recorded weight

7098 kg

Transmissions

12-speed

Production years

2005-2005

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerMüller (a part of Proton Primus)Reference

Four-wheel Drive (4WD) tractorReference

Built in BrazilReference

Four-wheel driveReference

Final drivesplanetaryReference

Articulated power steeringReference

Hydraulic disc brakesReference

Cab standard with air-conditioning.Reference

Engine

Cummins 6-cyl dieselReference

Engine113.3 kWReference

Cummins 6BT5.9Reference

turbocharged dieselReference

6-cylinderReference

liquid-cooledReference

Power113.3 kWReference

Fuel systemdirect injectionReference

Rated RPM2500Reference

Torque556.1 NmReference

Torque RPM1600Reference

StarterelectricReference

Starter volts12Reference

Coolant capacity37.0 LReference

Transmission

12-speedReference

Gears12 forward and 2 reverseReference

Clutchceramic discReference

Oil capacity21.0 LReference

Six speed gearbox with two-speed transfer case.Reference

Capacities

Fuel389.9 LReference

PTO & Hydraulics

Hydraulic system45.0 LReference

Capacity45.0 LReference

Dimensions

Wheelbase286 cmReference

Weight7098 kgReference

Front tire18.4/15x34Reference

Rear tire18.4/15x34Reference

Ag front18.4/15x34Reference

Ag rear18.4/15x34Reference

Ag front23.1/18x30Reference

Ag front23.1/18x26Reference

Ag rear23.1/18x30Reference

Ag rear23.1/18x26Reference

Length510 cmReference

Width238 cmReference

Height270 cmReference

Ballasted weight8500 kgReference

Electrical

Charging systemalternatorReference

Charging amps90Reference

Charging volts14Reference

Batteries2Reference

Battery volts12Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
