Tractor · 2005Unverified
Müller STA160
Müller STA160 — Four-wheel Drive (4WD) tractor · 152 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
152 hp
Weight
7098 kg
Hover a source tag to verify
Overview
ManufacturerMüller (a part of Proton Primus)Reference
Four-wheel Drive (4WD) tractorReference
Built in BrazilReference
Four-wheel driveReference
Final drivesplanetaryReference
Articulated power steeringReference
Hydraulic disc brakesReference
Cab standard with air-conditioning.Reference
Engine
Cummins 6-cyl dieselReference
Engine113.3 kWReference
Cummins 6BT5.9Reference
turbocharged dieselReference
6-cylinderReference
liquid-cooledReference
Power113.3 kWReference
Fuel systemdirect injectionReference
Rated RPM2500Reference
Torque556.1 NmReference
Torque RPM1600Reference
StarterelectricReference
Starter volts12Reference
Coolant capacity37.0 LReference
Transmission
12-speedReference
Gears12 forward and 2 reverseReference
Clutchceramic discReference
Oil capacity21.0 LReference
Six speed gearbox with two-speed transfer case.Reference
Capacities
Fuel389.9 LReference
PTO & Hydraulics
Hydraulic system45.0 LReference
Capacity45.0 LReference
Dimensions
Wheelbase286 cmReference
Weight7098 kgReference
Front tire18.4/15x34Reference
Rear tire18.4/15x34Reference
Ag front18.4/15x34Reference
Ag rear18.4/15x34Reference
Ag front23.1/18x30Reference
Ag front23.1/18x26Reference
Ag rear23.1/18x30Reference
Ag rear23.1/18x26Reference
Length510 cmReference
Width238 cmReference
Height270 cmReference
Ballasted weight8500 kgReference
Electrical
Charging systemalternatorReference
Charging amps90Reference
Charging volts14Reference
Batteries2Reference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
