Tractor · 1990Unverified
Müller TM310
Müller TM310 — Four-wheel Drive (4WD) tractor · 310 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
310 hp
Weight
13000 kg
Hover a source tag to verify
Overview
ManufacturerMüllerReference
Four-wheel Drive (4WD) tractorReference
Built in BrazilReference
Four-wheel driveReference
Final drivesplanetaryReference
Articulated power steeringReference
Hydraulic disc brakesReference
Cab standard with air-conditioning.Reference
Engine
Cummins 14.0L 6-cyl dieselReference
Engine231.2 kWReference
Cummins NTA-855AReference
turbocharged dieselReference
6-cylinderReference
liquid-cooled inlineReference
Displacement14.0 LReference
Bore/Stroke140 x 152 mmReference
Power231.2 kWReference
Starter typeelectricReference
Transmission
18-speedReference
TransmissionEatonReference
Gears18 forward and 4 reverseReference
Nine-speed gearbox with two-speed transfer case.Reference
Capacities
Fuel760.0 LReference
PTO & Hydraulics
Hydraulic system120.0 LReference
Capacity120.0 LReference
Dimensions
Wheelbase329 cmReference
Weight13000 kgReference
Length629 cmReference
Width350 cmReference
Ballasted weight15299 kgReference
Electrical
Charging systemalternatorReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
