The Murray 38701 is a lawn tractor with a rating of approximately 12 hp, a mid-range power figure for its class. It was manufactured in 1994 and features a 1-cylinder petrol air-cooled engine, paired with two-wheel drive and a 5-speed gearbox. The 38701 has an operating weight of 188 kg. It is suitable for operations covering up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
12 hp
Weight
188 kg
Catalogue coverage
Variants represented
2
Richest spec table
34 rows
Recorded power
12 hp
Transmissions
5-speed gear
Production years
1994-1994
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerMurrayReference
Lawn tractorReference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Engine
12HP Tecumseh 1-cyl gasolineReference
Fuel tank3.8 LReference
TecumsehReference
gasolineReference
1-cylinderReference
air-cooled vertical-shaftReference
Power (gross)8.9 kWReference
StarterelectricReference
Starter volts12Reference
Transmission
5-speed gearReference
Typebelt-driven gearReference
Gears5 forward and 1 reverseReference
Dimensions
Weight188 kgReference
Front tire15.00x6.00Reference
Rear tire18.00x9.50Reference
Lawn/turf front15.00x6.00Reference
Lawn/turf rear18.00x9.50Reference
Shipping weight188 kgReference
Murray 38701 attachments
38" mid-mount mower deckReference
snowblowerReference
bladeReference
Electrical
GroundnegativeReference
Battery volts12Reference
Attachment overview
38" mid-mount mower deckReference
SnowblowerReference
BladeReference
38" Mower deck
Typemid-mount MurrayReference
Typemanual liftReference
Cutting width96 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
