Lawn Tractor · 2023Unverified
Murray MT200
Murray MT200 — Lawn tractor · 19 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
19 hp
Weight
177 kg
Hover a source tag to verify
Overview
DistributorMurray (a part of Briggs & Stratton)Reference
ManufacturerNingbo DayeReference
Lawn tractorReference
Built in ChinaReference
Original price was $2,199 in 2023Reference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Engine
19HP Briggs & Stratton 540cc 1-cyl gasolineReference
Fuel tank5.3 LReference
Briggs & Stratton EX1900 33R8Reference
gasolineReference
1-cylinderReference
air-cooled vertical-shaftReference
Displacement33 ciReference
Bore/Stroke94 x 78 mmReference
Power (gross)14.2 kWReference
Air cleanerdryReference
StarterelectricReference
Starter volts12Reference
Oil capacity1.4 LReference
Oil change50 hReference
Sparkplug gap0.762 mmReference
Transmission
CVTReference
TransmissionDYMA220Reference
Typebelt-driven CVTReference
Gearsinfinite forward and reverseReference
PTO & Hydraulics
Mid PTOindependentReference
ClutchmanualReference
Dimensions
Weight177 kgReference
Front tire15x6.00-6Reference
Rear tire20x8.00-8Reference
Lawn/turf front15x6.00-6Reference
Lawn/turf rear20x8.00-8Reference
Length172 cmReference
Height105 cmReference
Murray MT200 attachments
42" mid-mount mower deckReference
MT200 Serial Number Location
Serial number decal on the rear fender deck, below the seat.Reference
Electrical
GroundnegativeReference
Charging amps9Reference
Battery CCA230Reference
Battery volts12Reference
Battery GroupU1Reference
42" Mower deck
Typemid-mount MurrayReference
Type2-blade with manual liftReference
Cutting width106 cmReference
DrivebeltReference
Overall width133 cmReference
Cut height2 to 10 cmReference
Cut positions13Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
