Tractor · 1996Unverified
New Holland 1215
New Holland 1215 — 15 Compact Series · 16 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
16 hp
Weight
1292 to 1360 pounds
Hover a source tag to verify
Overview
DistributorNew HollandReference
ManufacturerShibauraReference
Compact Utility tractorReference
Built in JapanReference
Original price was $9,000 in 1998Reference
Two- or four-wheel driveReference
Manual steeringReference
Wet disc brakesReference
Two-post fixed ROPS.Reference
Engine
Shibaura 0.9L 3-cyl dieselReference
Fuel tank18.2 LReference
Engine (gross)11.9 kWReference
Engine (net)10.4 kWReference
Shibaura S723Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement0.9 LReference
Bore/Stroke72 x 72 mmReference
Power (net)10.4 kWReference
Power (gross)11.9 kWReference
Rated RPM2500Reference
StarterelectricReference
Starter volts12Reference
Transmission
hydrostaticReference
6-speed gearReference
TypehydrostaticReference
Gearsinfinite forward and reverseReference
TypegearReference
Gears6 forward and 2 reverseReference
Three gears (1-3), plus reverse (R), in two ranges (L/H).Reference
PTO & Hydraulics
Gear PTO (claimed)10.1 kWReference
Hydro PTO (claimed)9.7 kWReference
Typeopen centerReference
Pump flow14.8 lpmReference
Rear TypeIReference
Rear lift (at ends)668 kgReference
Rear lift (at 24"/610mm)573 kgReference
Gear Rear PTOtransmissionReference
Hydro Rear PTOliveReference
Rear PTO Type540Reference
Mid PTOoptionalReference
Mid PTO Type2000Reference
Dimensions
Wheelbase140 cmReference
Weight1292 to 1360 poundsReference
Front tire4.00x12Reference
2WD Rear tire8x16Reference
2WD Standard tires (ag)Front: 4.00x12. Rear: 8x16Reference
4WD Standard tires (ag)Front: 5x12. Rear: 8x16Reference
Length270 cmReference
Width103 cmReference
Height (ROPS)203 cmReference
2WD Shipping weight586 kgReference
4WD Shipping weight616 kgReference
2WD Ground clearance25 cmReference
4WD Ground clearance24 cmReference
2WD Front tread85 to 89 cmReference
4WD Front tread82 cmReference
Rear tread85 to 99 cmReference
New Holland 1215 attachments
48" mid-mount mower deckReference
60" mid-mount mower deckReference
snowblowerReference
bladeReference
front-end loaderReference
backhoeReference
1215 Serial Numbers
Location:transmission housing on leftReference
1993UA20001Reference
1994UA20462Reference
1995UA21150Reference
1996UA21632Reference
1997UA21874Reference
1998UA22187Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Battery volts12Reference
Attachment overview
48" mid-mount mower deckReference
60" mid-mount mower deckReference
SnowblowerReference
BladeReference
Front-end loaderReference
BackhoeReference
Ford 756B Backhoe
Backhoe typeFord 756B BackhoeReference
Transport height146 cmReference
2-Foot flat digging depth198 cmReference
8-Foot flat digging depth130 cmReference
Loading height146 cmReference
Bucket Rotation180°Reference
Bucket force873 kgReference
Dipperstick force408 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
