Tractor · 1997Unverified
New Holland 1530
New Holland 1530 — Boomer Series · 25 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
25 hp
Weight
2318 to 2588 pounds
Hover a source tag to verify
Overview
DistributorNew HollandReference
ManufacturerShibauraReference
Compact Utility tractorReference
Original price was $14,000 in 1999Reference
Two- or four-wheel driveReference
Final drivesspur gearReference
Steeringhydrostatic powerReference
SteeringSuperSteer optionalReference
Wet disc brakesReference
Two-post fixed ROPS. Foldable ROPS optional.Reference
Engine
Shibaura 1.3L 3-cyl dieselReference
Fuel tank27.6 LReference
Engine (gross)18.6 kWReference
Engine (net)17.7 kWReference
ShibauraReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.3 LReference
Power (net)17.7 kWReference
Power (gross)18.6 kWReference
Fuel systemindirect injectionReference
Pre-heatingglow plugsReference
Rated RPM2600Reference
Starter volts12Reference
Transmission
9-speed sliding gearReference
hydrostaticReference
Typesliding gearReference
Gears9 forward and 3 reverseReference
Clutchdry discReference
TypehydrostaticReference
Gearsinfinite forward and reverse (3-range)Reference
PTO & Hydraulics
Gear PTO (claimed)16.2 kWReference
Hydro PTO (claimed)15.1 kWReference
Typeopen centerReference
Pressure147.1 barReference
Pump flow26.9 lpmReference
Total flow46.2 lpmReference
Steering flow19.3 lpmReference
Rear TypeIReference
Controlposition controlReference
Rear lift (at ends)871 kgReference
Rear lift (at 24"/610mm)741 kgReference
Rear PTOcontinuous liveReference
Rear PTO Type540Reference
Mid PTOlive (hydro)Reference
Mid PTO Type2000Reference
Dimensions
Wheelbase160 cmReference
SuperSteer Wheelbase182 cmReference
Weight2318 to 2588 poundsReference
Front tire5.50x16Reference
Rear tire11.2x24 (2WD)Reference
Standard tires (ag)Front: 5.50x16. Rear: 11.2x24 (2WD)Reference
Standard tires (ag)Front: 7x14. Rear: 11.2x24 (4WD)Reference
Lawn/turf front23x8.50-12 (2WD)Reference
Lawn/turf front25x8.50-14 (4WD)Reference
Lawn/turf rear13.6x16Reference
Industrial front25x8.50-14Reference
Industrial rear15-19.5Reference
2WD Length270 cmReference
4WD Length269 cmReference
SuperSteer Length292 cmReference
Width137 cmReference
Height (ROPS)223 cmReference
4WD Ground clearance38 cmReference
4WD Front tread110 cmReference
Rear tread108 cmReference
2WD Shipping1051 kgReference
4WD Shipping1122 kgReference
SuperSteer Shipping1173 kgReference
New Holland 1530 attachments
60" mid-mount mower deckReference
72" mid-mount mower deckReference
snowblowerReference
bladeReference
front-end loaderReference
backhoeReference
Electrical
GroundnegativeReference
Battery volts12Reference
Attachment overview
60" mid-mount mower deckReference
72" mid-mount mower deckReference
SnowblowerReference
BladeReference
Front-end loaderReference
BackhoeReference
New Holland 757C Backhoe
Backhoe typeNew Holland 757C BackhoeReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
