Tractor · 1997Unverified

New Holland 1630

Name: New Holland 1630
Brand: New Holland

New Holland 1630 — Boomer Series · 27 hp. Reference specifications; pending source verification.

The New Holland 1630 is a tractor with a rated power of 27 hp, categorised as a lighter model within its class. It was manufactured from 1997 to 1999. The 1630 features a 3-cylinder diesel liquid-cooled engine, paired with mechanical front-wheel drive and a hydrostatic transmission. Its operating weight is listed as 2474 to 2588 pounds.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

27 hp

Weight

2474 to 2588 pounds

Catalogue coverage

Variants represented

Richest spec table

83 rows

Recorded power

27 hp

Recorded weight

1122 kg

Transmissions

9-speed sliding gear

Production years

1997-1999

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

DistributorNew HollandReference

ManufacturerShibauraReference

Compact Utility tractorReference

Original price$16,200 (1999)Reference

Drive4x2 2WDReference

Drive4x4 MFWD 4WD (optional)Reference

Final drivesspur gearReference

Steeringhydrostatic powerReference

SteeringSuperSteer optionalReference

Wet disc brakesReference

Two-post fixed ROPS. Foldable ROPS optional.Reference

Engine

Shibaura 1.3L 3-cyl dieselReference

Fuel tank27.6 LReference

Engine (gross)20.4 kWReference

Engine (net)19.4 kWReference

ShibauraReference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement1.3 LReference

Power (net)19.4 kWReference

Power (gross)20.4 kWReference

Fuel systemindirect injectionReference

Pre-heatingglow plugsReference

Rated RPM2600Reference

Starter volts12Reference

Transmission

9-speed sliding gearReference

hydrostaticReference

Typesliding gearReference

Gears9 forward and 3 reverseReference

Clutchdry discReference

TypehydrostaticReference

Gearsinfinite forward and reverse (3-range)Reference

PTO & Hydraulics

Gear PTO (claimed)17.9 kWReference

Hydro PTO (claimed)16.8 kWReference

Typeopen centerReference

Pressure147.1 barReference

Pump flow26.9 lpmReference

Total flow46.2 lpmReference

Steering flow19.3 lpmReference

Rear Type1Reference

Controlposition controlReference

Rear lift (at ends)871 kgReference

Rear lift (at 24"/610mm)741 kgReference

Rear PTOcontinuous liveReference

Rear PTO Type540Reference

Mid PTOlive (hydro)Reference

Mid PTO Type2000Reference

Dimensions

Wheelbase160 cmReference

SuperSteer Wheelbase182 cmReference

Weight2474 to 2588 poundsReference

Front tire7-14Reference

Rear tire11.2-24Reference

Ag front7-14Reference

Ag rear11.2-24Reference

Lawn/turf front25x8.50-15Reference

Lawn/turf rear13.6-16Reference

Industrial front25x8.50-15Reference

Industrial rear15-19.5Reference

Length269 cmReference

SuperSteer Length292 cmReference

Width137 cmReference

Height (ROPS)223 cmReference

Shipping weight1122 kgReference

SuperSteer Shipping weight1173 kgReference

Ground clearance38 cmReference

Front tread110 cmReference

Rear tread108 cmReference

New Holland 1630 attachments

60" mid-mount mower deckReference

72" mid-mount mower deckReference

snowblowerReference

bladeReference

front-end loaderReference

backhoeReference

Electrical

GroundnegativeReference

Battery volts12Reference

Attachment overview

60" mid-mount mower deckReference

72" mid-mount mower deckReference

SnowblowerReference

BladeReference

Front-end loaderReference

BackhoeReference

New Holland 757C Backhoe

Backhoe typeNew Holland 757C BackhoeReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
