Tractor · 1996Unverified
New Holland 1715
New Holland 1715 — Compact Utility tractor · 27 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
27 hp
Weight
1929 to 2116 pounds
Hover a source tag to verify
Overview
ManufacturerNew HollandReference
Compact Utility tractorReference
Built in JapanReference
Original price was $11,500 in 1997Reference
Two- or four-wheel driveReference
Hydro SteeringpowerReference
Wet disc brakesReference
Two-post fixed ROPS.Reference
Engine
Shibaura 1.3L 3-cyl dieselReference
Fuel tank26.5 LReference
Engine (gross)20.4 kWReference
Engine (net)19.4 kWReference
ShibauraReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.3 LReference
Bore/Stroke84 x 80 mmReference
Power (net)19.4 kWReference
Power (gross)20.4 kWReference
Rated RPM2600Reference
StarterelectricReference
Starter volts12Reference
Transmission
9-speed gearReference
Gear SteeringmanualReference
TypegearReference
Gears9 forward and 3 reverseReference
Three gears, plus reverse, in three ranges.Reference
PTO & Hydraulics
PTO (claimed)17.2 kWReference
Typeopen centerReference
Pump flow23.1 lpmReference
Steering flow11.0 lpmReference
Rear TypeIReference
Rear lift (at ends)872 kgReference
Rear lift (at 24"/610mm)742 kgReference
Rear PTOtransmissionReference
Rear PTO Type540Reference
Mid PTOoptionalReference
Mid PTO Type2000Reference
Dimensions
Wheelbase160 cmReference
Weight1929 to 2116 poundsReference
Front tire4.00x15Reference
2WD Rear tire9.5x24Reference
2WD Standard tires (ag)Front: 4.00x15. Rear: 9.5x24Reference
4WD Standard tires (ag)Front: 6x14. Rear: 9.5x24Reference
Length285 cmReference
Width130 cmReference
Height (ROPS)214 cmReference
2WD Shipping weight874 kgReference
4WD Shipping weight959 kgReference
2WD Ground clearance29 cmReference
4WD Ground clearance28 cmReference
2WD Front tread102 to 107 cmReference
4WD Front tread107 cmReference
2WD Rear tread107 to 122 cmReference
4WD Rear tread104 to 119 cmReference
New Holland 1715 attachments
60" mid-mount mower deckReference
72" mid-mount mower deckReference
snowblowerReference
bladeReference
front-end loaderReference
backhoeReference
1715 Serial Numbers
Location:Transmission, left sideReference
1992UK20001Reference
1993UK20307Reference
1994UK22179Reference
1995UK25017Reference
1996UK27586Reference
1997UK29295Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Battery volts12Reference
Attachment overview
60" mid-mount mower deckReference
72" mid-mount mower deckReference
SnowblowerReference
BladeReference
Front-end loaderReference
BackhoeReference
Ford 757B Backhoe
Backhoe typeFord 757B BackhoeReference
Transport height180 cmReference
2-Foot flat digging depth215 cmReference
8-Foot flat digging depth165 cmReference
Loading height184 cmReference
Bucket Rotation180°Reference
Bucket force873 kgReference
Dipperstick force426 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
