Tractor · 1996Unverified

New Holland 2120

Name: New Holland 2120
Brand: New Holland

New Holland 2120 — Twenty Compact Series · 43 hp. Reference specifications; pending source verification.

The New Holland 2120 is a tractor model with a rated power output of 43 hp, positioning it at the lighter end of its class. Manufactured between 1996 and 2000, the 2120 is equipped with a 4-cylinder diesel liquid-cooled engine and four-wheel drive, paired with a 12-speed gearbox. It has an operating weight of 3572 to 3858 pounds, suitable for operations covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

43 hp

Weight

3572 to 3858 pounds

Catalogue coverage

Variants represented

Richest spec table

94 rows

Recorded power

43 hp

Recorded weight

1620 kg

Transmissions

12-speed gear

Production years

1996-2000

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

DistributorNew HollandReference

ManufacturerShibauraReference

Compact Utility tractorReference

Built in JapanReference

Original price$21,200Reference

Two- or four-wheel driveReference

Power steeringReference

Wet disc brakesReference

Two-post ROPS. Optional FOPS canopy.Reference

Engine

Shibaura 2.3L 4-cyl dieselReference

Fuel tank42.0 LReference

Engine (gross)31.8 kWReference

Engine (net)29.8 kWReference

Shibaura T854Reference

dieselReference

4-cylinderReference

liquid-cooledReference

Displacement2.3 LReference

Bore/Stroke85 x 100 mmReference

Power (net)29.8 kWReference

Power (gross)31.8 kWReference

Compression18:1Reference

Rated RPM2500Reference

StarterelectricReference

Starter volts12Reference

Coolant capacity8.0 LReference

Transmission

12-speed gearReference

12-speed power shuttleReference

TypegearReference

Gears12 forward and 4 reverseReference

Three gears (1-3) plus reverse (R) in four ranges.Reference

TransmissionHydraulic Shuttle Shift (HSS)Reference

Typepower shuttleReference

Gears12 forward and reverseReference

PTO & Hydraulics

PTO (claimed)25.7 kWReference

Typeopen centerReference

Pump flow35.2 lpmReference

Total flow45.8 lpmReference

Steering flow10.6 lpmReference

Rear TypeIReference

Controldraft controlReference

Rear lift (at 24"/610mm)1167 kgReference

Rear PTOindependentReference

Rear PTO Type540Reference

Dimensions

Wheelbase189 cmReference

Weight3572 to 3858 poundsReference

Front tire6.00x16Reference

2WD Rear tire13.6x28Reference

2WD Standard tires (ag)Front: 6.00x16. Rear: 13.6x28Reference

4WD Standard tires (ag)Front: 8.00-18. Rear: 13.6x28Reference

Lawn/turf front25x8.50-14Reference

Lawn/turf front27x8.50-15Reference

Lawn/turf rear14.9x26Reference

Lawn/turf rear18.4x16.1Reference

Length348 cmReference

Width157 cmReference

Height (ROPS)236 cmReference

2WD Shipping weight1620 kgReference

4WD Shipping weight1749 kgReference

4WD Ground clearance35 cmReference

2WD Ground clearance37 cmReference

2WD Front tread121 to 193 cmReference

4WD Front tread124 cmReference

Rear tread123 to 194 cmReference

New Holland 2120 attachments

bladeReference

front-end loaderReference

backhoeReference

2120 Serial Numbers

Location:Transmission housing, left sideReference

1988UV21003Reference

1989UV22274Reference

1990UV23599Reference

1991UV24295Reference

1992UV25141Reference

1993UV25891Reference

1994UV26738Reference

1995UV27935Reference

1996UV28911Reference

1997UV29898Reference

1998UV30679Reference

1999UV31770Reference

FAQ: How to read a serial number table.Reference

Electrical

GroundnegativeReference

Battery volts12Reference

Attachment overview

BladeReference

Front-end loaderReference

BackhoeReference

Ford 758B Backhoe

Backhoe typeFord 758B BackhoeReference

Transport height198 cmReference

2-Foot flat digging depth259 cmReference

8-Foot flat digging depth210 cmReference

Loading height199 cmReference

Bucket Rotation177°Reference

Bucket force1304 kgReference

Dipperstick force775 kgReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
