Tractor · 1997Unverified
New Holland 4330V
New Holland 4330V — Orchard/Vineyard tractor · 62 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
62 hp
Weight
3935 to 4122 pounds
Hover a source tag to verify
Overview
ManufacturerNew HollandReference
Orchard/Vineyard tractorReference
Original price was $25,500 in 2000Reference
Two- or four-wheel driveReference
Final drivesinboard planetaryReference
2WD Differential lockmechanicalReference
4WD Differential lockelectro-hydraulicReference
Power steeringReference
Mechanical wet disc brakesReference
Two-post mid-mount ROPS. Cab optional.Reference
Engine
Iveco 3.6L 4-cyl dieselReference
Fuel tank45.0 LReference
Engine52.2 kWReference
Iveco 8045.06Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.6 LReference
Bore/Stroke100 x 115 mmReference
Power52.2 kWReference
Pre-heatingthermostartReference
Compression17:1Reference
Rated RPM2500Reference
Firing order1-3-4-2Reference
Starter volts12Reference
Oil capacity11.7 LReference
Coolant capacity13.5 LReference
Transmission
12-speed mechanical shuttleReference
Typemechanical shuttleReference
Gears12 forward and reverseReference
Clutch279mm dry discReference
Oil capacity42.7 LReference
Four synchronized gears in three ranges with synchronized mechanical shuttle.Reference
PTO & Hydraulics
PTO (claimed)46.2 kWReference
Typeopen centerReference
Valves2Reference
Pump flow41.6 lpmReference
Steering flow30.7 lpmReference
Steering press.100.0 barReference
Rear TypeIReference
Controlposition control and lower-link draft sensingReference
Rear lift1960 kgReference
Rear PTOindependentReference
Clutchdry discReference
Rear PTO Type540/1000 (1.375)Reference
Dimensions
2WD Wheelbase195 cmReference
4WD Wheelbase203 cmReference
Weight3935 to 4122 poundsReference
Front tire6.00-16Reference
2WD Rear tire12.4-28Reference
2WD Standard tires (ag)Front: 6.00-16. Rear: 12.4-28Reference
4WD Standard tires (ag)Front: 7.00-12. Rear: 12.4-28Reference
2WD Length339 cmReference
4WD Length340 cmReference
Width119 cmReference
2WD Weight1784 kgReference
4WD Weight1869 kgReference
2WD Clearance (front axle)38 cmReference
4WD Clearance (front axle)29 cmReference
2WD Steering wheel135 cmReference
4WD Steering wheel132 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
ROPS Charging amps33Reference
Cab Charging amps65Reference
Battery volts12Reference
New Holland 4330V Height
2WD Hood123 cmReference
4WD Hood120 cmReference
2WD ROPS214 cmReference
4WD ROPS212 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
